CRL-2

YYZ Coral recessed LED downlights provides twiced reflection with extremely low glare even in presence of high luminous flux values. This IP65 rated warm LED light source is with aluminum body which provides protection from rain and humidity. It sets standards in terms of visual comfort, efficiency and quality of light for recessed luminaires. This series adopt the best technique of heat conduction, equip with heat resisting optic parts.

Technical data

Print technical data
  • complies with the European standard
  • IP65
LIGHT SOURCE LUMILEDS, CREE, NICHIA
MOUNTING CEILING RECESSED
LED COLOR 2700/3000/3500/4000 K
IP RATING IP65
DELIVERED LUMEN 1450 lm(15W)
1933 lm(20W)
RATED POWER 15/20 W
BEAM ANGLE 15°, 24°, 38°, 50°
BODY MATERIAL ALUMINUM
BODY FINISH WHITE,BLACK
LAMP LIFE 50,000 Hrs
CONNECTION OUTDOOR RATED CONNECTIONS
DIMENSIONS Ø110 x 108mm
SUPPLY VOLTAGE 220-240 V AC
DRIVER / POWER SUPPLY DETAILS ON/OFF
TRIAC
1-10V
DALI
DIMMING NON-DIMMABLE, TRIAC, 1-10V, DALI
CRI 90+
