LATTICE LARGE

YYZ Lattice series comprises single or twin lamps embedded beautifully in a square themed profile (small, medium, large size) with lamps of varied beam angles to match the architectural demands. These downlights are with symmetric light distribution which enables to achieve effective ambient lighting.

Technical data

Print technical data
  • complies with the European standard
  • IP20
LIGHT SOURCE LUMILEDS/CITIZEN
MOUNTING CEILING RECESSED
LED COLOR 2700/3000/3500/4000K
IP RATING IP20
DELIVERED LUMEN 90lm/W
RATED POWER 28/32 W
BEAM ANGLE 15º, 36º, 55º
BODY MATERIAL ALUMINUM
BODY FINISH WHITE,BLACK
LAMP LIFE 50,000 Hrs
CONNECTION INDOOR RATED CONNECTIONS
DIMENSIONS 160 x 160 x 139 mm
SUPPLY VOLTAGE 220-240V AC
DRIVER / POWER SUPPLY DETAILS ON/OFF
TRIAC
1-10V
DALI
DIMMING NON-DIMMABLE, TRIAC, 1-10V, DALI
CRI 90+
